$11,000.00
DC Electric Scissor Lift for sale! This narrow Skyjack SJIII3226 has robust steel construction – strong and durable.
Refurbished aerial lift platform in good working condition.
Drivable at full height
Variable speed, rear two wheel hydraulic drive
Dual holding brakes
Proportional controls for drive & lift functions
3’ (0.91 m) Roll out extension deck
24V DC power source
Low voltage battery protection
Up to 30% Gradeability
Solid rubber, non-marking tires
Pothole protection system
110V AC outlet on platform with GFI
28 mph wind rating (12.5 m/s)
Tilt alarm with drive & lift cut-out
All motion audible alarm
Lanyard attachment points
Operator horn
Hinged railing system (3226)
Forklift pockets and tie down/lift lugs
Relay based control system
Color coded and numbered wiring system
Telematics ready
Work Height – 32’ (9.75 m)
Raised Platform Height – 26’ (7.92 m)
Lowered Platform Height – 45” (1.14 m)
Overall Width – 32” (0.81 m)
Overall Length – 91.5” (2.32 m)
Stowed Height (Rails Up) – 84.7” (2.15 m)
Stowed Height (Rails Down) – 70.6” (1.79 m)
Platform Width (Inside Dimension) – 28” (0.71 m)
Platform Length (Inside Dimension) – 84” (2.13 m)
Extension Deck (Roll Out) – 3’ (0.91 m)
Ground Clearance (Stowed) – 3.5” (8.89 cm)
Ground Clearance (raised) – 0.75” (1.90 cm)
Wheelbase – 69” (1.75 m)
Weight – 4,135 lbs (1,876 kg)
Grade ability – 30%
Turning Radius (Inside) – 50” (1.27 m)
Turning Radius (Outside) – 108” (2.74 m)
Lift Time (With Rated Load) – 56 sec
Lower Time (With Rated Load) – 42 sec
Drive Speed (Stowed) – 2.4 mph (3.9 km/h)
Drive Speed (Raised) – 0.7 mph (1.1 km/h)
Maximum Drive Height – Full Height
Capacity (Overall) – 500 lbs (227 kg)
Distributed Capacity (Main Platform) – 250 lbs (113 kg)
Distributed Capacity (Extension Deck) – 250 lbs (113 kg)
Local Floor Load (With Rated Load) – 130 psi (897 kPa)
Overall Floor Load (With Rated Load) – 235 psf (12 kPa)
Maximum # of Persons – 2
Wind Rating – 28 mph (12.5 m/s)
Tire Type – Solid, N/M
Tire Size – 16 x 5 x 12
New batteries
New battery charger
New paint & decals
New tires
Rebuilt control box
